机闸一体铸铁闸门 Machine gate integrated cast iron gate

Views : 0 Update time : 2020-12-30 9:07:26

机闸一体铸铁闸门系列主要产品有:PGZ型铸铁闸门,PZ平板平面铸铁闸门,MZF铸铁方形闸门,MZY铸铁圆形闸门,AYZ铸铁暗杆圆闸门,AFZ铸铁暗杆方形闸门,SYZ铸铁镶铜圆形闸门,SFZ铸铁镶铜方形闸门,TYZ铸铁调节堰门,CM铸铁防潮门,双面止水铸铁闸门,CBZ插板闸门,ZSZ制水钢制闸门,DLZ叠梁闸门,PGZ平面定轮闸门,SLZ水利闸门,弧形闸门,液压翻板自控闸门,平面滑动钢闸门,水利机械及配件等。公司保始终紧跟水利技术的发展潮流,拥有大量先进的专利技术。

  The main products of machine gate integrated cast iron gate…

INQUIRY

   机闸一体铸铁闸门系列主要产品有:PGZ型铸铁闸门,PZ平板平面铸铁闸门,MZF铸铁方形闸门,MZY铸铁圆形闸门,AYZ铸铁暗杆圆闸门,AFZ铸铁暗杆方形闸门,SYZ铸铁镶铜圆形闸门,SFZ铸铁镶铜方形闸门,TYZ铸铁调节堰门,CM铸铁防潮门,双面止水铸铁闸门,CBZ插板闸门,ZSZ制水钢制闸门,DLZ叠梁闸门,PGZ平面定轮闸门,SLZ水利闸门,弧形闸门,液压翻板自控闸门,平面滑动钢闸门,水利机械及配件等。公司保始终紧跟水利技术的发展潮流,拥有大量先进的专利技术。

  The main products of machine gate integrated cast iron gate series are: PGZ type cast iron gate, PZ flat plane cast iron gate, mzf cast iron square gate, mzy cast iron round gate, ayz cast iron Non rising stem round gate, Afz cast iron Non rising stem square gate, SYZ cast iron copper inlaid round gate, sFz cast iron copper inlaid square gate, TYZ cast iron regulating weir gate, CM cast iron damp proof gate, double side water stop cast iron gate, CBZ gate, Zsz water steel gate, DLZ stoplog gate, PGZ plane fixed wheel gate, SLz hydraulic gate, radial gate, hydraulic flap automatic control gate, plane sliding steel gate, hydraulic machinery and accessories, etc. The company always keeps up with the development trend of water conservancy technology, and has a large number of advanced patented technologies.

  铸铁闸门:门叶的材料分为钢闸门、铸造闸门、木闸门、钢筋混凝土闸门和组合材料闸门。对于翻板闸门可借助水力自动启闭,称为水力自动闸门。

  Cast iron gate: the material of gate leaf is divided into steel gate, cast gate, wood gate, reinforced concrete gate and composite material gate. The flap gate can be opened and closed automatically by means of hydraulic power, which is called hydraulic automatic gate.

  直升式平面滑动:主要由闸框、闸板、吊座及紧闭斜铁等零部件组成。为克服以往钢门易锈蚀的缺点,闸框、闸板全采用铸铁组成,其中闸框又由上横梁、下横梁、左直梁、右直梁组成。为了制造、运输、安装方便,闸板一般根据其大小或高度情况由上下几部分拼装组成。

  Vertical plane sliding: mainly composed of gate frame, gate, suspension
 seat and closed inclined iron and other parts. In order to overcome the defects
 of steel door easy to rust in the past, the gate frame and gate are all made of

straight beam and right straight beam. For the convenience of manufacture,
cast iron, and the gate frame is composed of upper beam, lower beam, left
   transportation and installation, the ram is generally composed of upper and

lower parts according to its size or height.

  闸门按闸板形状的不同,分为PZ平板和PGZ拱形两大类。具体选用可根据闸孔尺寸、承压水头、启闭型式、闸门自重等方面加以综合比较确定。

  According to the different shape of gate, gate is divided into PZ flat
 plate and PGZ arch. The specific selection can be determined by comprehensive
 comparison of gate hole size, bearing head, opening and closing type, gate weight, etc.

  闸门按闸板结构的组合不同,分为整体式和组装式两大类。小规格的闸门一般制成整体式,但机械运输条件较差的施工安装点的闸门亦可制成组装式,以便于人工运输。中等规格以上的闸门一般均可制成组装式。

  According to the different shape of gate, gate is divided into PZ flat
 plate and PGZ arch. The specific selection can be determined by comprehensive
 comparison of gate hole size, bearing head, opening and closing type, gate weight, etc.







  机闸一体铸铁闸门:规格从0.2x0.2—6.5x6.5m(6.5x6.5m米水头号为6.5m米);出水口>=3米时,为双吊点闸门

  Cast iron gate: the specification is from 0.2x0.2 to 6.5x6.5m (6.5x6.5m,  the water head is 6.5m); when the water outlet is > 3M, it is a double lifting point gate

  机闸一体铸铁闸门结构设计:Structure design of machine gate integrated cast iron gate:

  主要由闸框和闸板两大部分组成。It is mainly composed of gate frame and gate.

  闸框是闸板的支承构件,也是闸板的运行滑道,由地脚螺栓安装固定在水闸闸墩及闸底板的二期混凝土中,将闸板所承受的全部水压力安全传递到闸室中。为科学合理节约材料及减轻自重,其断面制成格构式,断面尺寸按所受荷载大小和闸板运行情况综合考虑。

  The gate frame is not only the supporting component of the gate, but also  the running slide of the gate. It is installed and fixed in the phase II concrete of the pier and bottom plate of the gate by the anchor bolts, so as to safely transfer all the water pressure borne by the gate to the gate chamber. In order to save materials and reduce the dead weight scientifically and comprehensively considered according to the load and the ram operation.reasonably, the section is made into lattice structure, and the section size is


  机闸一体铸铁闸门规格齐全从0.2x0.2-6.5x6.5m(6.5x6.5m米水头高为6.5m米)并生产矩形铸铁闸门;口>=3米时,为双吊点闸门。
 机闸一体式铸铁闸门主要适用与正向受压止水,根据用户需要可制向止水闸门。 在结构上采用机加工硬止水,较大闸门底封水亦可采用橡胶封水。

根据用户要求,可采用镶铜或镶不锈钢止水。机闸一体式铸铁闸门正常使用水头1-6米,还可承受一定的反向水头,为用户要求,可制造高水头闸门。

The machine gate integrated cast iron gate has complete specifications, from 0.2x0.2 to 6.5x6.5m (6.5x6.5m water head height is 6.5m) and produces rectangular cast iron gate; when the gate mouth is more than 3m, it is double lifting point gate. The machine gate integrated cast iron gate is mainly used for sealing water under positive pressure, and the directional water stop gate can be made according to the needs of users. It can also use the hard water seal structure on the bottom of the gate. According to the user's requirements, copper inlaid or stainless steel inlaid water stop can be used. The machine gate integrated cast iron gate has a normal water head of 1-6m, and can also bear a certain reverse water head. It can be used to manufacture high water head gate according to the requirements of users.
