Single hoist hoist单吊卷扬启闭机

Views : 0 Update time : 2021-3-27 16:22:05

  Rongcheng hydraulic winch hoist has many models: QPQ ordinary winch hoist, qpk quick winch hoist, qpg high lift winch hoist, QPT trolley winch hoist.

  Application scope of single hoist hoist

  •

...

INQUIRY

  Rongcheng hydraulic winch hoist has many models: QPQ ordinary winch hoist, qpk quick winch hoist, qpg high lift winch hoist, QPT trolley winch hoist.

  Application scope of single hoist hoist

  •

  According to the design requirements of users' water conservancy projects, the machine is a kind of special machinery for water conservancy projects, which is widely used for the opening and closing of gates in water conservancy projects. It is a supporting machine for water intake and return gates in farmland irrigation, aquaculture, agricultural economic development zones, sewage treatment plants, water conservancy power stations, reservoirs (sluices, dams, tunnels, pipelines), etc., and can be used in mountainous areas, plains and areas without electricity.


  Operating procedures for single hoist hoist

  1. The construction unit should install the hoist on the flat and solid foundation with good vision, and the fuselage and ground anchor must be firm. It is required that the line between the hoist and the guide pulley should be vertically aligned, and the distance between the hoist and the pulley should not be less than 15m.


  2. Before adjusting and assembling, check the steel wire rope, clutch, brake, safety ratchet, transmission pulley, etc. to ensure safety and reliability before operation. The wire ropes must be arranged in order on the drum, and at least three circles shall be reserved during operation. During operation, no one is allowed to cross the wire rope of hoist to prevent accidents.

  3. When the heavy object needs to stay in the air, in addition to using the brake, ratchet safety should be used to fasten it. It is forbidden to leave the post without permission during operation.


  4. Obey the signal of the commander in the work. When the signal is unclear or may cause an accident, the operation shall be suspended and the operation can be continued after the situation is clear. In case of sudden power failure during operation, the knife switch shall be opened immediately and the transported objects shall be put down.


  Single hoist hoist is a kind of special machinery for water conservancy projects, which is widely used for the gate opening and closing of water conservancy projects. It is a supporting machinery for water intake and return sluice in farmland irrigation, aquaculture, agricultural economic development zone, sewage treatment plant, Water Conservancy Power Station, reservoir (sluice, dam, tunnel, pipeline), etc., which can be used in mountainous areas, plain areas with or without electricity.


  There are many types of winch hoist: QPQ ordinary winch hoist, qpk quick winch hoist, qpg high lift winch hoist, QPT trolley winch hoist. Winch hoist is divided into: flat door winch hoist; arc door winch hoist; double lifting point winch hoist; fast winch hoist; mobile trolley hoist; double lifting point winch hoist is divided into two types: centralized drive and separate drive; winch hoist manual and electric dual-purpose specification is divided into: 5T, 8t, 12.5t, 16t and 25t; winch hoist manual and electric dual-purpose specification is divided into: 5T, 8t, 12.5t, 16t and 25t; The specifications of electric type are: 40 tons, 63 tons, 80 tons, 100 tons, 125 tons, 160 tons, 200 tons. According to the design requirements of water conservancy projects of users, it can also produce double lifting point winch hoist. This machine is a kind of special machinery for water conservancy projects, which is widely used for the opening and closing of gates in water conservancy projects. It is widely used in agricultural irrigation, aquaculture, agricultural economic development zone, sewage treatment plant, Water Conservancy Power Station and reservoir( Water gate, dam, tunnel, pipeline) and other supporting machinery for water inlet and outlet sluice can be used in mountainous areas, plain areas with or without electricity. We can customize various types of water conservancy gate, hoist, gate and other series of water conservancy machinery and equipment products, supply to all regions of the country, welcome customers from all regions to negotiate cooperation!


  To learn more about products and view product classification series, you can call us directly, or scan wechat QR code to consult us directly or leave us a message.
